SQC-1200 Middel Block Cutting Machine

• Place of Origin:

   China

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1431199

• Place of Origin:

  China
• This machine has long span bridge structure. Moreover, the cross-beam and side-beams are made by excellent steel. The advanced imported parts are adopted in the electric control section that promise good quality and make this machine long life. In addition, the worktable can rotate 360°and has easy rotation and accurate orientation, which make cutting stably and high efficiency. Thus this machine is useful at processing stones with high value, tombstones and road edge stones .
  MIDDLE BLOCK CUTTING MACHINE
  Appellationunit SQC-1200A SQC-1200B
  Blade diametermm Φ600-Φ1200
  Max.vertical strokemm 630
  Worktable sizemm 3000×800 3800×800
  Worktable rotation range ° 0°- 360°
  Water consumption m3/h 4
  Power of main motor kw 18.5
  Total power kw 23.2
  Dimension(L×W×H) mm 6400×4000×4400 7000×4300×4400
  Total weight kg 6100(7400kg including steel base)6800(8200kg including steel base)
